O.S. OMA-5020-460 Brushless Motor

New product

Pilots loyal to outstanding O.S. performance but eager to fly electric now have the ideal option — powering electric airplanes using new O.S. brushless motors !

More details

$190.00 tax excl.

  • Legendary O.S. quality in a brushless electric motor! This one is intended as a replacement of .40 - .50 class 2 stroke and .70 class 4 stroke engines, using 5 or 6 cell Li-Po packs and will provide strong, linear power.

    This new range of brushless motors features a unique. O.S. designed cooling system, a strengthened centre body and large ball bearings. The propeller driver has been machined from stainless steel for both strength and durability.

    Each motor is balanced during manufacture for optimum running and reliability.

    Supplied with a rear mount and 4mm gold connectors as standard accessories.

    Note: To find out if this motor will suit your model please download the instructions as there are power charts showing the performance and setup you can achieve.


    Specifications
    Weight : 350g
    Turns : 16
    Bearings : 3
    Current Range : 50 - 60A
    ESC Timing Degrees
    : 20 - 30 Degrees
    KV RPM : 490
    Max Current : 90A for 10 secs
    Resistance : 23 mOhms
    Power Output : 1110W
    Nominal Voltage : 18.5 - 22.2v (5 - 6S Li-po)
    No Load Current : 1.5A
    Max Efficiency : 85%
    Shaft dia : 6mm
    Shaft Length : 11.5mm
